Steel wire rope statistical length coiled cut tied Machine WPM-40-80S

Steel wire rope coiling and cutting machine with statistical length measurement, equipped with cable bundling and meter counting function, as well as wire coil winding and binding capabilities. Additionally, it can also be used for cable rewinding.

The outer diameter of the winding dish 350mm

Cutting diameter <8mm

Tying wire length 120-200mm

Cable tie Rubber wrapped iron wire

Suitable coil diameter for tying 18-45mm

Voltage AC220V 50Hz/60Hz

Cable coil diameter 50-280mm

Rated Power <2500W

Winding speed 1-10 sec/circle

Weight 230KG

Dimensions L1000*W450*H800(mm)

Winding tolerance 25mm

Loading weight of winding wire <2.5KG

Efficiency 3*10-meter coils of cable/min without tying
