Heat Shrink Tube Insert Twist Tin Crimp Machine

  • Model No: WPM-006S

  • Specifications

    Heat shrink tube inserting and twisting tinning crimping machine WPM-006S
    Power: AC220v/50/60hz
    Capacity:1800pcs~2200pcs/H
    Function: wire cutting and stripping, one side twisting tinning another side crimping, and inserting heat shrink tube.
    Wire range: AWG24#~AWG12#
    Cutting length: 75-9999mm(can be customized)
    Cutting accuracy: 0.5mm+cutting lengthx0.2%
    Stripping length: 0-8mm.
    Pressure: 2.0T
    Air pressure: 5-6kgf
    Size: 1800*800*1860MM
    Weight: about 600kg
  • Inquiry now
Full automatic heat shrink tube inserting and twisting tinning crimping machine
1. It is a fully automatic wire processing machine for wire cutting, stripping, one side twisting tinning, and another side
terminal crimping and wearing the shrink tube, pulling off it, and heating it in the required position.
2. With a large processing wire range from AWG24# to AWG12#, All setting and adjustment procedures can be controlled from the LCD touchscreen.
3. One machine can crimp different terminals just change the crimping die, flexibility and change over time are short.
4. Integrated detector system, detect whether there is wire, whether there is terminal, whether there is air pressure, bad crimping, and tube
inserting checking etc guarantee the machine works excellently.

6. It is suitable for OPT side-feed/end-feed crimping die and Korean crimping die or European crimping dies as well.
Power: AC220v/50/60hz
Capacity:1800pcs~2200pcs/H
Function: wire cutting and stripping, one side twisting tinning another side crimping, and inserting heat shrink tube.
Wire range: AWG24#~AWG12#
Cutting length: 75-9999mm(can be customized)
Cutting accuracy: 0.5mm+cutting lengthx0.2%
Stripping length: 0-8mm.
Pressure: 2.0T
Air pressure: 5-6kgf
Size: 1800*800*1860MM
Weight: about 600kg
